IOL Con

1stQ
A4EW0M
AddOn progressiv (trifokal)

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
multifocal		Haptic Design:
4 loops Square		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 5 D (increment 0.25 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
A4FW00
AddOn torisch

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
4 loops Square		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-10 to 10 D (increment 0.25 D)
Cylinder:1.5 to 8.25 D (increment 0.75 D)
8.25 to 11 D (increment 1 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
A4MW00
AddOn SML

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
1.5 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
Haptic Design:
4 loops Square		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 D
Cylinder:-
Near Addition:10 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
A4SW00
AddOn sphärisch

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
4 loops Square		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 10 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B1ABY0
Basis Z hydrophob preloaded gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.7
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.222 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.4019
Holladay 1:SF = 1.6067
SRK/T:A = 118.645

Calculated from 46 clinical results.

IOL Con

1stQ
B1ADY0
Basis Z hydrophob gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.7
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB. Based on 97 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B1AP00
Basis Z preloaded

This lens is currently not available from the manufacturer/distributor.

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B1APY0
Basis Z preloaded gelb

This lens is currently not available from the manufacturer/distributor.

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B1AW00
Basis Z klar

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 45 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.325, a₁ = 0.255, a₂ = 0.141
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Adopted from ULIB. Based on 672 clinical results.

Optimized Constants

Haigis:a₀ = 1.011, a₁ = 0.335, a₂ = 0.101
Hoffer-Q:pACD = 5.0386
Holladay 1:SF = 1.2681
SRK/T:A = 118.13

Calculated from 852 clinical results.

IOL Con

1stQ
B1AWY0
Basis Z gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 45 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.325, a₁ = 0.255, a₂ = 0.141
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Adopted from ULIB. Based on 672 clinical results.

Optimized Constants

Haigis:a₀ = 1.011, a₁ = 0.335, a₂ = 0.101
Hoffer-Q:pACD = 5.0386
Holladay 1:SF = 1.2681
SRK/T:A = 118.13

Calculated from 852 clinical results.

IOL Con

1stQ
B1EWYN
Basis Z progressiv (trifokal) gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B1HWYN
Basis Z torisch-progressiv (trifokal) gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 35 D (increment 0.5 D)
Cylinder:1 to 4.5 D (increment 0.5 D)
4.5 to 6 D (increment 0.75 D)
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B1TWYT
Basis Z torisch gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:1.5 to 9 D (increment 0.75 D)
9 to 15 D (increment 1 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B2AP00
Basis Q preloaded klar

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Q-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.773, a₁ = 0.427, a₂ = 0.12
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.4069, a₁ = 0.4163, a₂ = 0.1713
Hoffer-Q:pACD = 5.5403
Holladay 1:SF = 1.7669
SRK/T:A = 118.965

Calculated from 219 clinical results.

IOL Con

1stQ
B2APY0
Basis Q preloaded gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Q-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-0 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.773, a₁ = 0.427, a₂ = 0.12
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B2AW00
Basis Q klar

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Q-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.278, a₁ = 0.427, a₂ = 0.12
Hoffer-Q:pACD = 5.02
Holladay 1:SF = 1.25
SRK/T:A = 118.95
Barrett:-
Olsen:-

Adopted from ULIB. Based on 601 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B2AWY0
Basis Q gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Q-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.278, a₁ = 0.427, a₂ = 0.12
Hoffer-Q:pACD = 5.02
Holladay 1:SF = 1.25
SRK/T:A = 118.95
Barrett:-
Olsen:-

Adopted from ULIB. Based on 601 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B2EWYM
Basis Q progressiv (trifokal) gelb Add. +3.00

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Q-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-0 to 30 D (increment 0.5 D)
30 to 35 D (increment 1 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B2EWYN
Basis Q progressiv (trifokal) gelb Add. +3.50

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Q-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-0 to 30 D (increment 0.5 D)
30 to 35 D (increment 1 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
B5ADY0
Basis V hydrophob gelb

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

1stQ
BASW00
Basis K

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop 6° angled		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.15
Holladay 1:SF = 1.37
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Aaren Scientific
Aqua 4 RMR

Specifications

Single Piece:
✔ yes		Optic Material:
Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
0.12 µm		Toric:
✘ no

Available Powers

Sphere:-
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
ARTIS Monofokal
Soft Hydrophobic Lens Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
2 mm
hydrophobic
Refractive Index:
1.54		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✘ no

Available Powers

Sphere:0 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 19.3
Haigis:a₀ = 0.088, a₁ = 0.233, a₂ = 0.2
Hoffer-Q:pACD = 6.095
Holladay 1:SF = 2.295
SRK/T:A = 119.74
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
ARTIS Toric
Soft Hydrophobic Lens Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophobic
Refractive Index:
1.54		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✔ yes

Available Powers

Sphere:10 to 35 D (increment 0.5 D)
Cylinder:0.75 to 6 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.3
Haigis:a₀ = 0.088, a₁ = 0.233, a₂ = 0.2
Hoffer-Q:pACD = 6.095
Holladay 1:SF = 2.295
SRK/T:A = 119.74
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
Claré
Hydrophilic Lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.59, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.75
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
EAZ-Y
Soft Hydrophobic Lens Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
2 mm
hydrophobic
Refractive Index:
1.59		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✘ no

Available Powers

Sphere:0 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.3
Haigis:a₀ = 1.77, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6.03
Holladay 1:SF = 2.33
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
SAL 302A
Soft Hydrophobic Preloaded Lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 1 D)
15 to 27 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
SAL 302AC
Soft Hydrophobic Preloaded Lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 1 D)
15 to 27 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
Softec 1
Hydrophilic Lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 36 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.92, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.22
Holladay 1:SF = 1.47
SRK/T:A = 118.43
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
Softec HD
Bi-aspheric Optic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 36 D (increment 1 D)
15 to 27 D (increment 0.5 D)
15 to 27 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.92, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.22
Holladay 1:SF = 1.47
SRK/T:A = 118.43
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Afidera
Softec HDY
Bi-aspheric Optic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 1 D)
15 to 27 D (increment 0.5 D)
15 to 27 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.92, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.22
Holladay 1:SF = 1.47
SRK/T:A = 118.43
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
A601250
AJL PMMA Lens

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
PMMA
Filter:
Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
6 mm		Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.495		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
anterior chamber
Optic Concept:
monofocal		Haptic Design:
Z FORM		Optic Design:
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 115.5
Haigis:a₀ = -0.177, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 3.51
Holladay 1:SF = 0.2
SRK/T:A = 116.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
F601250
AIALA

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 25 D (increment 0.5 D)
26 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.3
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.56
Holladay 1:SF = 1.37
SRK/T:A = 118
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
LLASHP60
AIALA DRY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.483		Abbe Number:
49		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C MODIFIED		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 27 D (increment 0.5 D)
28 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.2
Haigis:a₀ = 1.973, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.66
Holladay 1:SF = 1.37
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
LLASHP60PL
AIALA DRY PRELOADED

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.483		Abbe Number:
49		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C MODIFIED		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 27 D (increment 0.5 D)
28 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.2
Haigis:a₀ = 1.973, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.66
Holladay 1:SF = 1.37
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
LLASY60
AS IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Plate		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 25 D (increment 0.5 D)
26 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.3
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.56
Holladay 1:SF = 1.37
SRK/T:A = 118
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
LLY360
ORIOL MAX

This lens is currently not available from the manufacturer/distributor.

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.75 mm		Injector Size:

hydrophilic
Refractive Index:
1.462		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
PLATE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 25 D (increment 0.5 D)
26 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.3
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.56
Holladay 1:SF = 1.37
SRK/T:A = 118
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
LLY6002
ORIOL

This lens is currently not available from the manufacturer/distributor.

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.462		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
PLATE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 25 D (increment 0.5 D)
26 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.3
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.56
Holladay 1:SF = 1.37
SRK/T:A = 118
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
P651300
AJL PMMA Lens

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
6.5 mm		Injector Size:

hydrophilic
Refractive Index:
1.495		Abbe Number:
Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C FORM		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 12 D (increment 1 D)
12.5 to 25 D (increment 0.5 D)
26 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.273, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.96
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

AJL Ophthalmic
Y601075
INYECTABLE

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.75 mm		Injector Size:

hydrophilic
Refractive Index:
1.462		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
PLATE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 12 D (increment 1 D)
12.5 to 25 D (increment 0.5 D)
26 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.3
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.56
Holladay 1:SF = 1.37
SRK/T:A = 118
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof AU00T0
UltraSert

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = -0.769, a₁ = 0.234, a₂ = 0.217
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.84
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MA50BM
Multipiece - Posterior Convex

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10.5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.75, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.9
Holladay 1:SF = 2.12
SRK/T:A = 119.4
Barrett:-
Olsen:-

Adopted from ULIB. Based on 141 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MA60AC
Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 0.229, a₁ = 0.011, a₂ = 0.205
Hoffer-Q:pACD = 5.67
Holladay 1:SF = 1.9
SRK/T:A = 119.2
Barrett:-
Olsen:-

Adopted from ULIB. Based on 399 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MA60MA (-D)
Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 0 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -4.22, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = -5.52
Holladay 1:SF = -7.08
SRK/T:A = 103.6
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MA60MA (+D)
Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 5 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 5.78, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 15.94
Holladay 1:SF = 10.29
SRK/T:A = 126.6
Barrett:-
Olsen:-

Adopted from ULIB. Based on 91 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MN60AC
Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 0.229, a₁ = 0.011, a₂ = 0.205
Hoffer-Q:pACD = 5.67
Holladay 1:SF = 1.9
SRK/T:A = 119.2
Barrett:-
Olsen:-

Adopted from ULIB. Based on 399 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MN60MA (-D)
Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 0 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -4.22, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = -5.52
Holladay 1:SF = -7.08
SRK/T:A = 103.6
Barrett:-
Olsen:-

Adopted from ULIB. Based on 39 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MN60MA (+D)
Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 5 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 5.78, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 15.94
Holladay 1:SF = 10.29
SRK/T:A = 126.6
Barrett:-
Olsen:-

Adopted from ULIB. Based on 91 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof MN6AD1
ReSTOR +3.0 Multipiece

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.8
Haigis:a₀ = 1.901, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6.1
Holladay 1:SF = 2.31
SRK/T:A = 119.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SA60AT
Single-Piece

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.111, a₁ = 0.249, a₂ = 0.179
Hoffer-Q:pACD = 5.44
Holladay 1:SF = 1.67
SRK/T:A = 118.8
Barrett:-
Olsen:-

Adopted from ULIB. Based on 1867 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SA60WF
IQ

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = -0.769, a₁ = 0.234, a₂ = 0.217
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.84
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB. Based on 5363 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SA6AT (2-9)
IQ Toric UV-only

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:-
Cylinder:
(t-notation)		T2: 1 DT3: 1.5 D
T4: 2.25 DT5: 3 D
T6: 3.75 DT7: 4.5 D
T8: 5.25 DT9: 6 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = -0.323, a₁ = 0.213, a₂ = 0.208
Hoffer-Q:pACD = 5.81
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SN60AT
Single-Piece

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.111, a₁ = 0.249, a₂ = 0.179
Hoffer-Q:pACD = 5.44
Holladay 1:SF = 1.67
SRK/T:A = 118.8
Barrett:-
Olsen:-

Adopted from ULIB. Based on 1867 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SN60WF
IQ

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = -0.769, a₁ = 0.234, a₂ = 0.217
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.84
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB. Based on 5363 clinical results.

Optimized Constants

Haigis:a₀ = 0.693, a₁ = 0.341, a₂ = 0.135
Hoffer-Q:pACD = 5.48
Holladay 1:SF = 1.7
SRK/T:A = 118.85

Calculated from 214 clinical results.

IOL Con

Alcon
AcrySof SN6AD1
IQ ReSTOR +3.0dpt

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.385, a₁ = 0.197, a₂ = 0.204
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.84
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB. Based on 885 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SN6AT (2-9)
IQ Toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:
(t-notation)		T2: 1 DT3: 1.5 D
T4: 2.25 DT5: 3 D
T6: 3.75 DT7: 4.5 D
T8: 5.25 DT9: 6 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = -0.323, a₁ = 0.213, a₂ = 0.208
Hoffer-Q:pACD = 5.81
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Adopted from ULIB. Based on 584 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SN6CWS
AcrySert

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = -0.769, a₁ = 0.234, a₂ = 0.217
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.84
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB. Based on 5363 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SND1T (2-6)
IQ ReSTOR Toric +3.0dpt

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:
(t-notation)		T2: 1 DT3: 1.5 D
T4: 2.25 DT5: 3 D
T6: 3.75 D
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.385, a₁ = 0.197, a₂ = 0.204
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.84
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB. Based on 885 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SV25T0
IQ ReSTOR +2.5dpt

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:-
Near Addition:2.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.66, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.82
Holladay 1:SF = 2.07
SRK/T:A = 119.5
Barrett:-
Olsen:-

Adopted from ULIB. Based on 70 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof SV25T (2-6)
IQ ReSTOR Toric +2.5dpt

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:
(t-notation)		T2: 1 DT3: 1.5 D
T4: 2.25 DT5: 3 D
T6: 3.75 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.66, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.82
Holladay 1:SF = 2.07
SRK/T:A = 119.5
Barrett:-
Olsen:-

Adopted from ULIB. Based on 70 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof TFNT00
IQ PanOptix

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:13 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:-
Near Addition:3.25 D
Intermediate Addition:2.17 D

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.39, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.63
Holladay 1:SF = 1.83
SRK/T:A = 119.1
Barrett:-
Olsen:-

Adopted from ULIB. Based on 26 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
AcrySof TFNT (20-60)
IQ PanOptix Toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:13 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:
(t-notation)		T2: 1 DT3: 1.5 D
T4: 2.25 DT5: 3 D
T6: 3.75 D
Near Addition:3.25 D
Intermediate Addition:2.17 D

Manufacturer Provided Constants

Nominal:-
Haigis:a₀ = 1.39, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.63
Holladay 1:SF = 1.83
SRK/T:A = 119.1
Barrett:-
Olsen:-

Adopted from ULIB. Based on 26 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
Clareon CNA0T0
AutonoMe

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
3 mm
hydrophobic
Refractive Index:
1.55		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
STABLEFORCE		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:-
Hoffer-Q:-
Holladay 1:SF = 1.824
SRK/T:A = 119.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.16, a₁ = 0.2, a₂ = 0.2
Hoffer-Q:pACD = 5.76
Holladay 1:SF = 1.97
SRK/T:A = 119.26

Calculated from 558 clinical results.

IOL Con

Alcon
PMMA MTA3U0
Anterior Chamber Lens

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
5.5 mm		Haptic Ø:
12.5 mm		Intended Location:
anterior chamber
Optic Concept:
monofocal		Haptic Design:
Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 115.3
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Alcon
PMMA MTA4U0
Anterior Chamber Lens

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
5.5 mm		Haptic Ø:
13 mm		Intended Location:
anterior chamber
Optic Concept:
monofocal		Haptic Design:
Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 115.3
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
Akreos Adapt
ADAPTTP

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
four-point-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.96, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.14
Holladay 1:SF = 1.4
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
Akreos Adapt AO
ADAPTAOP

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
four-point-haptic		Optic Design:
sphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.94, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.18
Holladay 1:SF = 1.4
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
Akreos MICS
MI60P

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
four-point-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.49, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.67
Holladay 1:SF = 1.9
SRK/T:A = 119.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
enVista
MX60P

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.54		Abbe Number:
40.5		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 34 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 1.46, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.68
Holladay 1:SF = 1.91
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.037, a₁ = 0.2957, a₂ = 0.1871
Hoffer-Q:pACD = 5.8841
Holladay 1:SF = 2.0768
SRK/T:A = 119.419

Calculated from 635 clinical results.

IOL Con

Bausch + Lomb
enVista toric
MX60TP

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.54		Abbe Number:
40.5		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:6 to 30 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:1.25 to 5.75 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.46, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.68
Holladay 1:SF = 1.91
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
Eye-CEE
EYECPRE

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = 1.55, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.95
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
EyeCee One
EYEC1

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.14 µm		Toric:
✘ no

Available Powers

Sphere:1 to 30 D (increment 1 D)
10 to 27 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.675, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6
Holladay 1:SF = 2.13
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
EyeCee One CRYSTAL
EYEC1CRY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.14 µm		Toric:
✘ no

Available Powers

Sphere:1 to 30 D (increment 1 D)
10 to 27 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.675, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6
Holladay 1:SF = 2.13
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
EyeCee One CRYSTAL Preloaded
EYEC1CRYPRE

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.14 µm		Toric:
✘ no

Available Powers

Sphere:11 to 27 D (increment 0.5 D)
27 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.675, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6
Holladay 1:SF = 2.13
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
EyeCee One Preloaded
EYEC1PRE

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.14 µm		Toric:
✘ no

Available Powers

Sphere:11 to 27 D (increment 0.5 D)
27 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.675, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6
Holladay 1:SF = 2.13
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
INCISE
MJ14T

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
four-point-haptic		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.35, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
Quatrix Evolutive

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophilic
Refractive Index:
1.465		Abbe Number:
Achromatic:
Optic Ø:
6.14 mm		Haptic Ø:
10.8 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
four-point-haptic		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.6
Haigis:a₀ = 1.91, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 6.04
Holladay 1:SF = 2.28
SRK/T:A = 119.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
SofPort AO
LI61AOR Sulcus fixation possible

Specifications

Single Piece:
✘ no		Optic Material:
silicone		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.43		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 34 D (increment 1 D)
5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.057, a₁ = 0.186, a₂ = 0.171
Hoffer-Q:pACD = 5.29
Holladay 1:SF = 1.51
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Bausch + Lomb
Versario Classic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.465		Abbe Number:
Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✘ no

Available Powers

Sphere:-10 to 40 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 120
Haigis:a₀ = 1.8, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.96
Holladay 1:SF = 2.2
SRK/T:A = 119.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.8626 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 6.0001
Holladay 1:SF = 2.2601
SRK/T:A = 119.79

Calculated from 54 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex AXIS TMFA6
HYDROPHOBIC ASPHERIC NATURAL YELLOW TORIC IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:1 to 1.5 D (increment 0.5 D)
1.5 to 6 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.3, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.45
Holladay 1:SF = 1.66
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.975, a₁ = 0.3428, a₂ = 0.2087
Hoffer-Q:pACD = 5.5477
Holladay 1:SF = 1.7639
SRK/T:A = 118.852

Calculated from 145 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex GENE MPA6
HYDROPHILIC ASPHERIC MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 15 D (increment 1 D)
15 to 25 D (increment 0.5 D)
25 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.03, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.13
Holladay 1:SF = 1.37
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.9715, a₁ = 0.3575, a₂ = 0.1844
Hoffer-Q:pACD = 4.9033
Holladay 1:SF = 1.1265
SRK/T:A = 117.913

Calculated from 102 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex GENESIS COMFORT LMFAC6
PRELOADED HYDROPHOBIC ASPHERIC MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.925 mm
hydrophobic
Refractive Index:
1.524		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.03, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.25
Holladay 1:SF = 1.46
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0687 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2979
Holladay 1:SF = 1.5178
SRK/T:A = 118.493

Calculated from 96 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex GENESIS COMFORT NY LMFA6
PRELOADED HYDROPHOBIC ASPHERIC NATURAL YELLOW MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.925 mm
hydrophobic
Refractive Index:
1.524		Abbe Number:
47		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.03, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.25
Holladay 1:SF = 1.46
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0687 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2979
Holladay 1:SF = 1.5178
SRK/T:A = 118.493

Calculated from 96 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex GENESIS MFA6
HYDROPHOBIC ASPHERIC NATURAL YELLOW MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.077, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.51
SRK/T:A = 118.65
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.7923 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.9628
Holladay 1:SF = 2.1853
SRK/T:A = 119.488

Calculated from 60 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex MPS6
HYDROPHILIC MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 1 D (increment 1 D)
1 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.94, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.19
Holladay 1:SF = 1.42
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.7581 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.0455
Holladay 1:SF = 1.2369
SRK/T:A = 118.037

Calculated from 52 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex OPUS AXIS TDFA6
HYDROPHOBIC ASPHERIC NATURAL YELLOW MULTIFOCAL TORIC IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:1 to 1.5 D (increment 0.5 D)
1.5 to 3 D (increment 0.75 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 0.838, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.07
Holladay 1:SF = 1.28
SRK/T:A = 118.29
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.9711 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.1814
Holladay 1:SF = 1.4221
SRK/T:A = 118.321

Calculated from 72 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex OPUS D3FA6
HYDROPHOBIC ASPHERIC NATURAL YELLOW MULTIFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:7.5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.24, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.42
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0399 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2942
Holladay 1:SF = 1.503
SRK/T:A = 118.592

Calculated from 83 clinical results.

IOL Con

Biotech Europe Meditech
Optiflex TRIO 3FLA6
HYDROPHOBIC ASPHERIC NATURAL YELLOW TRIFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
2.8 mm
hydrophobic
Refractive Index:
1.52		Abbe Number:
47		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:7 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.85 D

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.11, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.33
Holladay 1:SF = 1.55
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.9642 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2242
Holladay 1:SF = 1.4339
SRK/T:A = 118.365

Calculated from 71 clinical results.

IOL Con

Biotech Vision Care
EYECRYL ACTV
HYDROPHOBIC ASPHERIC NATURAL YELLOW MULTIFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:7.5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.24, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.42
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0399 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2942
Holladay 1:SF = 1.503
SRK/T:A = 118.592

Calculated from 83 clinical results.

IOL Con

Biotech Vision Care
EYECRYL ACTV TORIC HFYD
HYDROPHOBIC ASPHERIC NATURAL YELLOW MULTIFOCAL TORIC IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:1 to 1.5 D (increment 0.5 D)
1.5 to 3 D (increment 0.75 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 0.838, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.07
Holladay 1:SF = 1.28
SRK/T:A = 118.29
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.9711 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.1814
Holladay 1:SF = 1.4221
SRK/T:A = 118.321

Calculated from 72 clinical results.

IOL Con

Biotech Vision Care
EYECRYL PLUS 600
HYDROPHILIC MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 1 D (increment 1 D)
1 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.94, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.19
Holladay 1:SF = 1.42
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.7581 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.0455
Holladay 1:SF = 1.2369
SRK/T:A = 118.037

Calculated from 52 clinical results.

IOL Con

Biotech Vision Care
EYECRYL PLUS ASHFY600
HYDROPHOBIC ASPHERIC NATURAL YELLOW MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.2, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.43
Holladay 1:SF = 1.63
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -1.4054, a₁ = 0.124, a₂ = 0.2522
Hoffer-Q:pACD = 5.4706
Holladay 1:SF = 1.671
SRK/T:A = 118.767

Calculated from 146 clinical results.

IOL Con

Biotech Vision Care
EYECRYL PLUS CLEAR HSAS600
HYDROPHILIC ASPHERIC MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 15 D (increment 1 D)
15 to 25 D (increment 0.5 D)
25 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.03, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.13
Holladay 1:SF = 1.37
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.9715, a₁ = 0.3575, a₂ = 0.1844
Hoffer-Q:pACD = 4.9033
Holladay 1:SF = 1.1265
SRK/T:A = 117.913

Calculated from 102 clinical results.

IOL Con

Biotech Vision Care
EYECRYL PLUS NATURAL HD ASHFY6002
HYDROPHOBIC ASPHERIC NATURAL YELLOW MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.925 mm
hydrophobic
Refractive Index:
1.524		Abbe Number:
47		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.077, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.51
SRK/T:A = 118.65
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.7923 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.9628
Holladay 1:SF = 2.1853
SRK/T:A = 119.488

Calculated from 60 clinical results.

IOL Con

Biotech Vision Care
EYECRYL SERT PAHFY600F
PRELOADED HYDROPHOBIC ASPHERIC NATURAL YELLOW MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.925 mm
hydrophobic
Refractive Index:
1.524		Abbe Number:
47		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.03, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.25
Holladay 1:SF = 1.46
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0687 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2979
Holladay 1:SF = 1.5178
SRK/T:A = 118.493

Calculated from 96 clinical results.

IOL Con

Biotech Vision Care
EYECRYL SERT PLHF2
PRELOADED HYDROPHOBIC ASPHERIC MONOFOCAL IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.925 mm
hydrophobic
Refractive Index:
1.524		Abbe Number:
47		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✘ no

Available Powers

Sphere:5 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.03, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.25
Holladay 1:SF = 1.46
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0687 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2979
Holladay 1:SF = 1.5178
SRK/T:A = 118.493

Calculated from 96 clinical results.

IOL Con

Biotech Vision Care
EYECRYL TORIC HFY
HYDROPHOBIC ASPHERIC NATURAL YELLOW TORIC IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:
1.975 mm
hydrophobic
Refractive Index:
1.48		Abbe Number:
49		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.2 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:1 to 1.5 D (increment 0.5 D)
1.5 to 6 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.3, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.45
Holladay 1:SF = 1.66
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.975, a₁ = 0.3428, a₂ = 0.2087
Hoffer-Q:pACD = 5.5477
Holladay 1:SF = 1.7639
SRK/T:A = 118.852

Calculated from 145 clinical results.

IOL Con

Cutting Edge
Genesis
Genesis Preloaded Screw (GOPS) or push (GOPP)

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.555		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 1.777, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.43
Holladay 1:SF = 1.68
SRK/T:A = 118.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.4582 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.6334
Holladay 1:SF = 1.8232
SRK/T:A = 118.975

Calculated from 32 clinical results.

IOL Con

Cutting Edge
SIP
Synthesis Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
1.5 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.589, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.51
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.2228 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.4595
Holladay 1:SF = 1.7064
SRK/T:A = 118.851

Calculated from 82 clinical results.

IOL Con

Cutting Edge
SIPY
Synthesis Yellow Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
1.5 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.589, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.51
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.2228 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.4595
Holladay 1:SF = 1.7064
SRK/T:A = 118.851

Calculated from 82 clinical results.

IOL Con

Cutting Edge
SISA
Synthesis

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.5 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.589, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.51
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.2228 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.4595
Holladay 1:SF = 1.7064
SRK/T:A = 118.851

Calculated from 82 clinical results.

IOL Con

Cutting Edge
SISAY
Synthesis Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.5 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.589, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.51
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.2228 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.4595
Holladay 1:SF = 1.7064
SRK/T:A = 118.851

Calculated from 82 clinical results.

IOL Con

Cutting Edge
Synthesis Plus
Synthesis Plus EDOF: PPLUS (clear) and PYPLUS (yellow)

Specifications

Single Piece:
Optic Material:
Haptic Material:
Filter:
Preloaded:
Foldable:
Incision Width:
Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
Haptic Ø:
Intended Location:
Optic Concept:
Haptic Design:
Optic Design:
Sph. Aberration:
SA Correction:
Toric:

Available Powers

Sphere:-
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.2228, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.4595
Holladay 1:SF = 1.7064
SRK/T:A = 118.851
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.107 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.3363
Holladay 1:SF = 1.59
SRK/T:A = 118.665

Calculated from 30 clinical results.

IOL Con

Hanita Lenses
B-Lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.4 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C-loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:1 to 7 D (increment 1 D)
8 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 1.004, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.23
Holladay 1:SF = 1.44
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.7128 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.0008
Holladay 1:SF = 1.2946
SRK/T:A = 118.176

Calculated from 53 clinical results.

IOL Con

Hanita Lenses
BunnyLens AF

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 0.978, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.2
Holladay 1:SF = 1.42
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Hanita Lenses
BunnyLens HP

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.42, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.58
Holladay 1:SF = 1.77
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.3729 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.5529
Holladay 1:SF = 1.7309
SRK/T:A = 118.868

Calculated from 58 clinical results.

IOL Con

Hanita Lenses
BunnyLens MF
FullRange

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 0.978, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.2
Holladay 1:SF = 1.42
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Hanita Lenses
PerfecTor

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Plate		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.4
Haigis:a₀ = 0.448, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.86
Holladay 1:SF = 1.02
SRK/T:A = 117.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Hanita Lenses
SeeLens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.4 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C-loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:1 to 7 D (increment 1 D)
8 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.044, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.48
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0524 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2752
Holladay 1:SF = 1.4103
SRK/T:A = 118.328

Calculated from 52 clinical results.

IOL Con

Hanita Lenses
SeeLens AF

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C-loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.6
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.2833 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.42
Holladay 1:SF = 1.627
SRK/T:A = 118.713

Calculated from 71 clinical results.

IOL Con

Hanita Lenses
SeeLens HP

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C-loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 40 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.5
Haigis:a₀ = 1.38, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.56
Holladay 1:SF = 1.8
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.2885 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.4643
Holladay 1:SF = 1.7156
SRK/T:A = 118.872

Calculated from 61 clinical results.

IOL Con

Hanita Lenses
SeeLens MF
FullRange

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C-loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.044, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.48
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 2.30936, a₁ = 0.24018, a₂ = 0.07106
Hoffer-Q:pACD = 5.345
Holladay 1:SF = 1.59112
SRK/T:A = 118.687

Calculated from 418 clinical results.

IOL Con

Hanita Lenses
Vistor

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV+violet		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Plate		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.4
Haigis:a₀ = 0.448, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.86
Holladay 1:SF = 1.02
SRK/T:A = 117.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
150
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.93 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
151
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.93 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
250
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.82 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
251
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.82 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.17099 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.28983
Holladay 1:SF = 1.59361
SRK/T:A = 118.795

Calculated from 22 clinical results.

IOL Con

HOYA
254
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.78 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
255
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.78 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
351
iSert Toric

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.82 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:
(t-notation)		T3: 1.5 DT4: 2.25 D
T5: 3 DT6: 3.75 D
T7: 4.5 DT8: 5.25 D
T9: 6 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
PC-60AD
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.89 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.093, a₁ = -0.023, a₂ = 0.208
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.54
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
PC-60R
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.89 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.06, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.24
Holladay 1:SF = 1.48
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
PY-60AD
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.89 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.093, a₁ = -0.023, a₂ = 0.208
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.54
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
PY-60R
iSert

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.89 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.06, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.24
Holladay 1:SF = 1.48
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
VA-60BB

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
2.13 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:4 to 40 D (increment 0.5 D)
-7 to 3 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.24, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.43
Holladay 1:SF = 1.65
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
VA-65BB

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
2.25 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:4 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.31, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.65
Holladay 1:SF = 1.74
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
XC1
Vivinex iSert

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.7 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.905, a₁ = 0.23, a₂ = 0.229
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -1.0517, a₁ = 0.18821, a₂ = 0.23929
Hoffer-Q:pACD = 5.72099
Holladay 1:SF = 1.95429
SRK/T:A = 119.23

Calculated from 1127 clinical results.

IOL Con

HOYA
XC1-SP
Vivinex multiSert

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.7 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.905, a₁ = 0.23, a₂ = 0.229
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -1.0517, a₁ = 0.18821, a₂ = 0.23929
Hoffer-Q:pACD = 5.72099
Holladay 1:SF = 1.95429
SRK/T:A = 119.23

Calculated from 1127 clinical results.

IOL Con

HOYA
XY1
Vivinex iSert

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.7 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.905, a₁ = 0.23, a₂ = 0.229
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -1.0517, a₁ = 0.18821, a₂ = 0.23929
Hoffer-Q:pACD = 5.72099
Holladay 1:SF = 1.95429
SRK/T:A = 119.23

Calculated from 1127 clinical results.

IOL Con

HOYA
XY1A
Vivinex Toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.7 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:
(t-notation)		T2: 1 DT3: 1.5 D
T4: 2.25 DT5: 3 D
T6: 3.75 DT7: 4.5 D
T8: 5.25 DT9: 6 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.905, a₁ = 0.23, a₂ = 0.229
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
XY1-SP
Vivinex multiSert

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:
1.7 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = -0.905, a₁ = 0.23, a₂ = 0.229
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.98
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -1.0517, a₁ = 0.18821, a₂ = 0.23929
Hoffer-Q:pACD = 5.72099
Holladay 1:SF = 1.95429
SRK/T:A = 119.23

Calculated from 1127 clinical results.

IOL Con

HOYA
YA-60BB

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
2.13 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:4 to 40 D (increment 0.5 D)
-7 to 3 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.3, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.5
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
YA-60BBR

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
1.89 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:4 to 40 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.06, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.24
Holladay 1:SF = 1.48
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HOYA
YA-65BB

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
2.25 mm
hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:4 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.31, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.65
Holladay 1:SF = 1.74
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
ASPIRA-aA

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-20 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 60 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = -0.6, a₁ = 0.152, a₂ = 0.209
Hoffer-Q:pACD = 5.37
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.86579, a₁ = 0.21309, a₂ = 0.21406
Hoffer-Q:pACD = 5.37354
Holladay 1:SF = 1.62583
SRK/T:A = 118.716

Calculated from 937 clinical results.

IOL Con

HumanOptics
ASPIRA-aA Safeloader
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-20 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 60 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = -0.6, a₁ = 0.152, a₂ = 0.209
Hoffer-Q:pACD = 5.37
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.86579, a₁ = 0.21309, a₂ = 0.21406
Hoffer-Q:pACD = 5.37354
Holladay 1:SF = 1.62583
SRK/T:A = 118.716

Calculated from 937 clinical results.

IOL Con

HumanOptics
ASPIRA-aAY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-20 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 60 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = -0.6, a₁ = 0.152, a₂ = 0.209
Hoffer-Q:pACD = 5.37
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.86579, a₁ = 0.21309, a₂ = 0.21406
Hoffer-Q:pACD = 5.37354
Holladay 1:SF = 1.62583
SRK/T:A = 118.716

Calculated from 937 clinical results.

IOL Con

HumanOptics
ASPIRA-aAY Safeloader
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-20 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 60 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = -0.6, a₁ = 0.152, a₂ = 0.209
Hoffer-Q:pACD = 5.37
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.86579, a₁ = 0.21309, a₂ = 0.21406
Hoffer-Q:pACD = 5.37354
Holladay 1:SF = 1.62583
SRK/T:A = 118.716

Calculated from 937 clinical results.

IOL Con

HumanOptics
ASPIRA-aQA

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
quattro-haptics		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.432, a₁ = 0.016, a₂ = 0.231
Hoffer-Q:pACD = 5.61
Holladay 1:SF = 1.8
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.49132, a₁ = 0.072, a₂ = 0.22674
Hoffer-Q:pACD = 5.60457
Holladay 1:SF = 1.80473
SRK/T:A = 118.952

Calculated from 295 clinical results.

IOL Con

HumanOptics
ASPIRA-aXA
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
7 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
palte with cut-out		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.667, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.89
Holladay 1:SF = 2.13
SRK/T:A = 119.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.6673 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.8916
Holladay 1:SF = 2.1259
SRK/T:A = 119.503

Calculated from 58 clinical results.

IOL Con

HumanOptics
DIFF-aA

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 1.28, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.5
Holladay 1:SF = 1.73
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
DIFF-aA Safeloader
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 1.28, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.5
Holladay 1:SF = 1.73
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
DIFF-aAY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 1.28, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.5
Holladay 1:SF = 1.73
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
DIFF-aAY Safeloader
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 1.28, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.5
Holladay 1:SF = 1.73
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
TORICA-aA

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-20 to 40 D (increment 0.5 D)
Cylinder:1 to 25 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 1.18, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.35
Holladay 1:SF = 1.51
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
TORICA-aAY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-20 to 40 D (increment 0.5 D)
Cylinder:1 to 25 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 1.18, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.35
Holladay 1:SF = 1.51
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
TORICADIFF-aA

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 0.885, a₁ = 0.312, a₂ = 0.125
Hoffer-Q:pACD = 5.36
Holladay 1:SF = 1.6
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
TORICADIFF-aA Safeloader
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 0.885, a₁ = 0.312, a₂ = 0.125
Hoffer-Q:pACD = 5.36
Holladay 1:SF = 1.6
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
TORICADIFF-aAY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 0.885, a₁ = 0.312, a₂ = 0.125
Hoffer-Q:pACD = 5.36
Holladay 1:SF = 1.6
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

HumanOptics
TORICADIFF-aAY Safeloader
Preloaded Safeloader autoloading container

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.1
Haigis:a₀ = 0.885, a₁ = 0.312, a₂ = 0.125
Hoffer-Q:pACD = 5.36
Holladay 1:SF = 1.6
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
AAB00
SENSAR 1PC

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Haptics offset from optic		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = -1.004, a₁ = 0.182, a₂ = 0.232
Hoffer-Q:pACD = 5.56
Holladay 1:SF = 1.78
SRK/T:A = 119
Barrett:-
Olsen:-

Adopted from ULIB. Based on 415 clinical results.

Optimized Constants

Haigis:a₀ = -0.13383, a₁ = 0.34617, a₂ = 0.16861
Hoffer-Q:pACD = 5.44304
Holladay 1:SF = 1.71699
SRK/T:A = 118.937

Calculated from 153 clinical results.

IOL Con

Johnson & Johnson Vision
AR40e
Sensar 3PC

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Modified C		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:-
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.62
SRK/T:-
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
AR40E
Sensar 3PC

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Modified C		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:2 to 5.5 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -2.42, a₁ = 0.157, a₂ = 0.288
Hoffer-Q:pACD = 5.41
Holladay 1:SF = 1.63
SRK/T:A = 118.7
Barrett:-
Olsen:-

Adopted from ULIB. Based on 653 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
AR40M
Sensar 3PC

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Modified C		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 1.5 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:-
Hoffer-Q:pACD = 5.41
Holladay 1:SF = 1.63
SRK/T:-
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ICB00
Tecnis Eyhance

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Haptics offset from optic		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:pACD = 5.7
Holladay 1:SF = 1.96
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
PCB00
TECNIS ITEC PRELOADED

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Haptics offset from optic		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.3
Haigis:-
Hoffer-Q:pACD = 5.7
Holladay 1:SF = 1.96
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
PCB00V
TECNIS ITEC PRELOADED OPTIBLUE

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV. violett		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Haptics offset from optic		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = -0.329, a₁ = 0.332, a₂ = 0.203
Hoffer-Q:pACD = 5.98
Holladay 1:SF = 2.18
SRK/T:A = 119.5
Barrett:-
Olsen:-

Adopted from ULIB. Based on 247 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
VRSA54
Verisyse IOL

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
Filter:
UV		Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.49		Abbe Number:
Achromatic:
Optic Ø:
5.4 mm		Haptic Ø:
8.5 mm		Intended Location:
pre iridal
Optic Concept:
monofocal		Haptic Design:
Optic Design:
Sph. Aberration:
SA Correction:
Toric:

Available Powers

Sphere:2 to 14.5 D (increment 1 D)
14.5 to 24.5 D (increment 0.5 D)
24.5 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 115
Haigis:a₀ = -0.5, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.34
Holladay 1:SF = 0.54
SRK/T:A = 116.9
Barrett:-
Olsen:-

Adopted from ULIB. Based on 20 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZA9003
TECNIS 3PC

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Modified C		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.1
Haigis:a₀ = -1.298, a₁ = 0.233, a₂ = 0.24
Hoffer-Q:pACD = 5.61
Holladay 1:SF = 1.84
SRK/T:A = 119.1
Barrett:-
Olsen:-

Adopted from ULIB. Based on 1309 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZCB00
TECNIS 1PC CLEAR

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Haptics offset from optic		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = -1.302, a₁ = 0.21, a₂ = 0.251
Hoffer-Q:pACD = 5.8
Holladay 1:SF = 2.02
SRK/T:A = 119.3
Barrett:-
Olsen:-

Adopted from ULIB. Based on 2041 clinical results.

Optimized Constants

Haigis:a₀ = -1.99752, a₁ = 0.19533, a₂ = 0.28562
Hoffer-Q:pACD = 5.85303
Holladay 1:SF = 2.0613
SRK/T:A = 119.396

Calculated from 206 clinical results.

IOL Con

Johnson & Johnson Vision
ZCB00V
TECNIS 1PC OPTIBLUE MONO

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
UV. violett		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Haptics offset from optic		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = -0.329, a₁ = 0.332, a₂ = 0.203
Hoffer-Q:pACD = 5.98
Holladay 1:SF = 2.18
SRK/T:A = 119.5
Barrett:-
Olsen:-

Adopted from ULIB. Based on 247 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZCT
TECNIS TORIC 1PIECE ZCT

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:5 to 34 D (increment 0.5 D)
Cylinder:
(t-notation)		ZCT100: 1 DZCT150: 1.5 D
ZCT225: 2.25 DZCT300: 3 D
ZCT375: 3.75 DZCT450: 4.5 D
ZCT525: 5.25 DZCT600: 6 D
ZCT700: 7 DZCT800: 8 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 2.1572 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 6.30077
Holladay 1:SF = 2.51928
SRK/T:A = 120.229

Calculated from 23 clinical results.

IOL Con

Johnson & Johnson Vision
ZCV00
TECNIS OPTIBLUE TORIC 1PIECE ZCV00

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
UV. violett		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:5 to 34 D (increment 0.5 D)
Cylinder:1.5 to 3.75 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZFR00V
Tecnis Synergy IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
UV. violett		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:pACD = 5.4
Holladay 1:SF = 1.68
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZKB00
Tecnis MIOL 1 Piece ZKB00

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:2.75 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZLB00
Tecnis MIOL 1 Piece ZLB00

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:3.25 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZMA00
TECNIS MULTIFOCAL ZMA00

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:4 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.1
Haigis:a₀ = -1.75, a₁ = 0.242, a₂ = 0.266
Hoffer-Q:pACD = 5.8
Holladay 1:SF = 2.06
SRK/T:A = 119.5
Barrett:-
Olsen:-

Adopted from ULIB. Based on 205 clinical results.

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZMB00
Tecnis MIOL 1 Piece ZMB00

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:4 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZMT
TECNIS MULTIFOCAL TORIC 1PIECE ZMT

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:5 to 34 D (increment 0.5 D)
Cylinder:
(t-notation)		ZMT150: 1.5 DZMT225: 2.25 D
ZMT300: 3 DZMT400: 4 D
Near Addition:4 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Johnson & Johnson Vision
ZXR00
TECNIS SYMFONY 1PIECE ZXR00

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.18858, a₁ = 0.17155, a₂ = 0.1977
Hoffer-Q:pACD = 5.59053
Holladay 1:SF = 1.82584
SRK/T:A = 119.057

Calculated from 487 clinical results.

IOL Con

Johnson & Johnson Vision
ZXT
TECNIS SYMFONY TORIC 1PIECE ZXT

Specifications

Single Piece:
Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
1.47		Abbe Number:
Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:5 to 34 D (increment 0.5 D)
Cylinder:
(t-notation)		ZXT100: 1 DZXT150: 1.5 D
ZXT225: 2.25 DZXT300: 3 D
ZXT375: 3.75 DZXT450: 4.5 D
ZXT525: 5.25 DZXT600: 6 D
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
CP2.2
Avansee Preload1P Clear

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.6
Haigis:a₀ = 1.557, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.69
Holladay 1:SF = 1.87
SRK/T:A = 119.03
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
CP2.2R
Avansee Preload1P Clear

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.6
Haigis:a₀ = 1.557, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.69
Holladay 1:SF = 1.87
SRK/T:A = 119.03
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
PN6A
AvanseePreset

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PVDF
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.57, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.85
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
PN6AS
AvanseePreset

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PVDF
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.57, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.85
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
PU6A
AvanseePresetUV

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PVDF
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.57, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.85
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
PU6AS
AvanseePresetUV

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PVDF
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.57, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.64
Holladay 1:SF = 1.85
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
YP2.2
Avansee Preload1P

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.6
Haigis:a₀ = 1.557, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.69
Holladay 1:SF = 1.87
SRK/T:A = 119.03
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Kowa
YP2.2R
Avansee Preload1P

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.519		Abbe Number:
43.4		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.04 µm		Toric:
✘ no

Available Powers

Sphere:6 to 10 D (increment 1 D)
10 to 26 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.6
Haigis:a₀ = 1.557, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.69
Holladay 1:SF = 1.87
SRK/T:A = 119.03
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
HD3

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13.25 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified C Loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 36 D (increment 1 D)
10.5 to 29.5 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:-
Hoffer-Q:pACD = 5.04
Holladay 1:SF = 1.03
SRK/T:A = 118.13
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
HDM

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 36 D (increment 1 D)
10.5 to 29.5 D (increment 0.5 D)
15.25 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:pACD = 4.85
Holladay 1:SF = 1.11
SRK/T:A = 117.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
HP1

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophobic
Refractive Index:
Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified C		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:-
Hoffer-Q:pACD = 5.37
Holladay 1:SF = 1.62
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
SBL-2

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
bifocal		Haptic Design:
Modified Plate		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:10 to 36 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.537, a₁ = 0.333, a₂ = 0.126
Hoffer-Q:pACD = 4.99
Holladay 1:SF = 1.18
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
SBL-3

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
5.75 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
bifocal		Haptic Design:
Modified Plate		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:10 to 36 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.537, a₁ = 0.333, a₂ = 0.126
Hoffer-Q:pACD = 4.99
Holladay 1:SF = 1.18
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
Softec HD

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 36 D (increment 1 D)
10.5 to 29.5 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:-
Hoffer-Q:pACD = 5.22
Holladay 1:SF = 1.47
SRK/T:A = 118.43
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
Softec HDO

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
Haptic Ø:
12.5 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 36 D (increment 1 D)
10.5 to 29.5 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:-
Hoffer-Q:pACD = 5.28
Holladay 1:SF = 1.48
SRK/T:A = 118.54
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
Softec HDY

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
5.75 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified C		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 36 D (increment 1 D)
10.5 to 29.5 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:-
Hoffer-Q:pACD = 5.22
Holladay 1:SF = 1.47
SRK/T:A = 118.43
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Lenstec
Tetraflex HD

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
57		Achromatic:
✘ no
Optic Ø:
5.75 mm		Haptic Ø:
Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Modified Plate		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:5 to 15 D (increment 0.5 D)
15 to 25 D (increment 0.25 D)
25 to 30 D (increment 0.5 D)
30 to 36 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:-
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.54
SRK/T:A = 118.57
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 677AB
Hydrophilic monofocal

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 45 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.325, a₁ = 0.255, a₂ = 0.141
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 677ABY
Hydrophilic monofocal yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 45 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.325, a₁ = 0.255, a₂ = 0.141
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 677TA
Hydrophilic monofocal toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:-10 to 1 D (increment 1 D)
0 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:1 to 1.5 D (increment 1.5 D)
1.5 to 9 D (increment 0.75 D)
10 to 24 D (increment 1 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 677TAY
Hydrophilic monofocal toric yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:-10 to 1 D (increment 1 D)
0 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:1 to 1.5 D (increment 1.5 D)
1.5 to 9 D (increment 0.75 D)
10 to 24 D (increment 1 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 877FAB
Hydrophobic monofocal

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.47		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Fenestrated		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.7
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 877FABY
Hydrophobic monofocal yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.47		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Fenestrated		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.7
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 877PA
Hydrophobic monofocal preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.4 mm
hydrophobic
Refractive Index:
1.47		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Fenestrated		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.7
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex 877PAY
Hydrophobic monofocal yellow filter preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.4 mm
hydrophobic
Refractive Index:
1.47		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Fenestrated		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.7
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex PILMA 677P
Hydrophilic monofocal preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.4 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Bi-Flex PILMA 677PY
Hydrophilic monofocal yellow filter preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.4 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Liberty 677MTY
Hydrophilic trifocal toric yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:8 to 35 D (increment 0.5 D)
Cylinder:1 to 4.5 D (increment 0.5 D)
5.25 to 6 D (increment 0.75 D)
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Liberty 677MY
Hydrophilic trifocal yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:8 to 35 D (increment 1 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Liberty 677PMY
Hydrophilic trifocal yellow filter preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:8 to 35 D (increment 1 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Liberty Toric 677MTY
Hydrophilic trifocal toric yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:8 to 35 D (increment 0.5 D)
Cylinder:1 to 4.5 D (increment 0.5 D)
5.25 to 6 D (increment 0.75 D)
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Q-Flex 640AB
Hydrophilic monofocal

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.7 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4 closed loops		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.278, a₁ = 0.427, a₂ = 0.12
Hoffer-Q:pACD = 5.02
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Q-Flex 640ABY
Hydrophilic monofocal yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.7 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4 closed loops		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.278, a₁ = 0.427, a₂ = 0.12
Hoffer-Q:pACD = 5.02
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Q-Flex 640MY
Hydrophilic trifocal yellow filter

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.7 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
4 closed loops		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:0 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Q-Flex 640P
Hydrophilic monofocal preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.7 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4 closed loops		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:0 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Medicontur
Q-Flex 640PY
Hydrophilic monofocal yellow filter preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
10.7 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4 closed loops		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:0 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.243, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.46
Holladay 1:SF = 1.67
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Millennium Biomedical
SAL 300A
PreciSAL

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.26, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.61
SRK/T:A = 118.7
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = 1.2471 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.3584
Holladay 1:SF = 1.6052
SRK/T:A = 118.626

Calculated from 49 clinical results.

IOL Con

Millennium Biomedical
SAL 300AC
PreciSAL

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.26, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.61
SRK/T:A = 118.7
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = 1.2471 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.3584
Holladay 1:SF = 1.6052
SRK/T:A = 118.626

Calculated from 49 clinical results.

IOL Con

Millennium Biomedical
SAL 302A
PreciSAL

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.70119, a₁ = 0.11934, a₂ = 0.22226
Hoffer-Q:pACD = 5.49901
Holladay 1:SF = 1.74071
SRK/T:A = 118.899

Calculated from 224 clinical results.

IOL Con

Millennium Biomedical
SAL 302AC
PreciSAL

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.70119, a₁ = 0.11934, a₂ = 0.22226
Hoffer-Q:pACD = 5.49901
Holladay 1:SF = 1.74071
SRK/T:A = 118.899

Calculated from 224 clinical results.

IOL Con

Millennium Biomedical
SAL P302A
PreciSAL -Preloaded

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.70119, a₁ = 0.11934, a₂ = 0.22226
Hoffer-Q:pACD = 5.49901
Holladay 1:SF = 1.74071
SRK/T:A = 118.899

Calculated from 224 clinical results.

IOL Con

Millennium Biomedical
SAL P302AC
PreciSAL-Preloaded

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.70119, a₁ = 0.11934, a₂ = 0.22226
Hoffer-Q:pACD = 5.49901
Holladay 1:SF = 1.74071
SRK/T:A = 118.899

Calculated from 224 clinical results.

IOL Con

Millennium Biomedical
SAL PT302A
PreciSAL TORIC -Preloaded

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
UV		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.21657, a₁ = 0.21988, a₂ = 0.18543
Hoffer-Q:pACD = 5.44056
Holladay 1:SF = 1.64804
SRK/T:A = 118.763

Calculated from 247 clinical results.

IOL Con

Oculentis
FB-313
FEMTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
5.7 mm		Haptic Ø:
10.5 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:15 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.8
Haigis:a₀ = 0.515, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.75
Holladay 1:SF = 0.97
SRK/T:A = 117.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
FB-313 MF15
FEMTIS Comfort

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
5.7 mm		Haptic Ø:
10.5 mm		Intended Location:
Optic Concept:
EDOF		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:15 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:1.5 D

Manufacturer Provided Constants

Nominal:A = 117.8
Haigis:a₀ = 0.515, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.75
Holladay 1:SF = 0.97
SRK/T:A = 117.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
L-301-1
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.05, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.19
Holladay 1:SF = 1.39
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
L-302-1
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
c-loop haptik		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.833, a₁ = 0.138, a₂ = 0.096
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.35
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
L-303
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:10.5 to 30 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.962, a₁ = -0.074, a₂ = 0.161
Hoffer-Q:pACD = 5.13
Holladay 1:SF = 1.36
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
L-312
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
c-loop haptik		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10.5 to 29.5 D (increment 0.5 D)
-10 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = -2.476, a₁ = 0.046, a₂ = 0.3
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.5
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
L-313
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10.5 to 29.5 D (increment 0.5 D)
-10 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.82, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.26
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
L-323
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
10 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.82, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.26
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-302Y
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
c-loop haptik		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.833, a₁ = 0.138, a₂ = 0.096
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.35
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-311Y
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-312Y
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
c-loop haptik		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.86, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.04
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-313 MF15
LENTIS Comfort

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 0.5 D)
-10 to -1 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:1.5 D

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.21
Holladay 1:SF = 1.47
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.01857, a₁ = 0.30891, a₂ = 0.10725
Hoffer-Q:pACD = 5.1519
Holladay 1:SF = 1.38037
SRK/T:A = 118.328

Calculated from 361 clinical results.

IOL Con

Oculentis
LS-313 MF15 T0-T6
LENTIS Comfort toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:10 to 30 D (increment 0.5 D)
Cylinder:0.75 to 5.25 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:1.5 D

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.70598, a₁ = 0.27389, a₂ = 0.1273
Hoffer-Q:pACD = 5.18541
Holladay 1:SF = 1.33629
SRK/T:A = 118.191

Calculated from 189 clinical results.

IOL Con

Oculentis
LS-313 MF20
LENTIS Mplus

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 0.5 D)
-10 to -1 D (increment 1 D)
Cylinder:-
Near Addition:2 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.21
Holladay 1:SF = 1.47
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.1419 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.3811
Holladay 1:SF = 1.5687
SRK/T:A = 118.663

Calculated from 43 clinical results.

IOL Con

Oculentis
LS-313 MF30
LENTIS Mplus

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 0.5 D)
-10 to -1 D (increment 1 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.21
Holladay 1:SF = 1.47
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-313 MF30
LENTIS MplusX

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 0.5 D)
-10 to -1 D (increment 1 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.21
Holladay 1:SF = 1.47
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.0207 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.2471
Holladay 1:SF = 1.4956
SRK/T:A = 118.493

Calculated from 49 clinical results.

IOL Con

Oculentis
LS-313 T1-T6
LENTIS Tplus

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:1.5 to 5.25 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.97, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.18
Holladay 1:SF = 1.37
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-313Y
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:10.5 to 29.5 D (increment 0.5 D)
-10 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.02, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.19
Holladay 1:SF = 1.43
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-412Y
LENTIS

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
3.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
c-loop haptik		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
-10 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.88, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.07
Holladay 1:SF = 1.3
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LS-412Y
LENTIS

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
3.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
c-loop haptik		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
-10 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 MF15T
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:-
Intermediate Addition:1.5 D

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.70598, a₁ = 0.27389, a₂ = 0.1273
Hoffer-Q:pACD = 5.18541
Holladay 1:SF = 1.33629
SRK/T:A = 118.191

Calculated from 189 clinical results.

IOL Con

Oculentis
LU-313 MF15TY
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
EDOF		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:-
Intermediate Addition:1.5 D

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.70598, a₁ = 0.27389, a₂ = 0.1273
Hoffer-Q:pACD = 5.18541
Holladay 1:SF = 1.33629
SRK/T:A = 118.191

Calculated from 189 clinical results.

IOL Con

Oculentis
LU-313 MF20T
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:2 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 MF20TY
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:2 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 MF30T
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 MF30T
LENTIS MplusX toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 MF30TY
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 MF30TY
LENTIS MplusX toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.87, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 T
LENTIS TplusX

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-10 to 35 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.97, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.18
Holladay 1:SF = 1.37
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-313 TY
LENTIS TplusX

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate haptik design		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-10 to 35 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.97, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.18
Holladay 1:SF = 1.37
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 MF30
LENTIS Mplus

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 0.5 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = 1.56, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.71
Holladay 1:SF = 1.94
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 MF30
LENTIS Mplus

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 36 D (increment 0.5 D)
Cylinder:-
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 MF30T
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = 1.56, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.71
Holladay 1:SF = 1.94
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 MF30T
LENTIS Mplus toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:0 to 36 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:3 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 T
LENTIS TplusX

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:-10 to 35 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = 1.56, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.71
Holladay 1:SF = 1.94
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 T
LENTIS TplusX

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:-10 to 35 D (increment 0.01 D)
Cylinder:0.25 to 12 D (increment 0.01 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
LU-814 VR
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119
Haigis:a₀ = 1.56, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.71
Holladay 1:SF = 1.94
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = -0.41349, a₁ = 0.2203, a₂ = 0.20543
Hoffer-Q:pACD = 5.7052
Holladay 1:SF = 1.95504
SRK/T:A = 119.258

Calculated from 128 clinical results.

IOL Con

Oculentis
LU-814 VR
LENTIS

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6.2 mm		Haptic Ø:
13 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:15.5 to 26.5 D (increment 0.5 D)
0 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Oculentis
W-60 R

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yes		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:

hydrophobic
Refractive Index:
1.54		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.13 µm		Toric:

Available Powers

Sphere:10 to 15 D (increment 1 D)
15.5 to 24.5 D (increment 0.5 D)
25 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.48, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.73
Holladay 1:SF = 1.97
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Ophtec
AC 205
Artisan Aphakia. anterior fixation

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
5.6 mm		Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.492		Abbe Number:
Achromatic:
Optic Ø:
5.4 mm		Haptic Ø:
8.5 mm		Intended Location:
pre iridal
Optic Concept:
monofocal		Haptic Design:
Iris claw		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:2 to 30 D (increment 1 D)
14.5 to 24.5 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 115
Haigis:a₀ = -0.16, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 3.62
Holladay 1:SF = -0.08
SRK/T:A = 115.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Ophtec
AC 205
Artisan Aphakia. posterior fixation

Specifications

Single Piece:
✔ yes		Optic Material:
PMMA		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✘ no
Incision Width:
5.6 mm		Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.492		Abbe Number:
Achromatic:
Optic Ø:
5.4 mm		Haptic Ø:
8.5 mm		Intended Location:
retro iridal
Optic Concept:
monofocal		Haptic Design:
Iris Claw		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:2 to 30 D (increment 1 D)
14.5 to 24.5 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 116.8
Haigis:a₀ = -0.25, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.34
Holladay 1:SF = 0.54
SRK/T:A = 116.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Ophtec
PC 545
QuadrimaX

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4 closed loops		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:5 to 35 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.408, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.81
SRK/T:A = 119
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Ophtec
PC 560
Precizon Monofocal

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Offset shaped		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 0 D (increment 0.5 D)
1 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.567, a₁ = 0.123, a₂ = 0.159
Hoffer-Q:pACD = 5.27
Holladay 1:SF = 1.53
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.05354 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.29939
Holladay 1:SF = 1.45183
SRK/T:A = 118.311

Calculated from 48 clinical results.

IOL Con

Ophtec
PC 565
Precizon Toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Offset shaped		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sphere:1 to 34 D (increment 0.5 D)
Cylinder:1 to 10 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.567, a₁ = 0.123, a₂ = 0.159
Hoffer-Q:pACD = 5.27
Holladay 1:SF = 1.53
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Ophtec
PC 570
Precizon Presbyopic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.462		Abbe Number:
47		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Offset shaped		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:1 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:2.75 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.567, a₁ = 0.123, a₂ = 0.159
Hoffer-Q:pACD = 5.27
Holladay 1:SF = 1.53
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 0.15527, a₁ = 0.0833, a₂ = 0.1829
Hoffer-Q:pACD = 5.27261
Holladay 1:SF = 1.53171
SRK/T:A = 118.565

Calculated from 121 clinical results.

IOL Con

PhysIOL
Ankoris
Monofocal Hydrophilic Toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✔ yes

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:1.5 to 6 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.95
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.83
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micro+ A
Monofocal Hydrophilic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6.15 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:-10 to -1 D (increment 1 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.52
Holladay 1:SF = 1.74
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micro+ A 123
Monofocal Hydrophilic preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6.15 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.52
Holladay 1:SF = 1.74
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micro+ AY
Monofocal Hydrophilic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6.15 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.52
Holladay 1:SF = 1.74
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micro+ AY 123
Monofocal Hydrophilic Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6.15 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.52
Holladay 1:SF = 1.74
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micro F
FineVision Trifocal Hydrophilic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6.15 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:10 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.35
Holladay 1:SF = 1.6
SRK/T:A = 118.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micropure
Monofocal Hydrophobic G-free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.52		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:-10 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.4
Haigis:a₀ = 1.7, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.85
Holladay 1:SF = 2.06
SRK/T:A = 119.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Micropure 123
Monofocal Hydrophobic G-free Preloaded

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.52		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.4
Haigis:a₀ = 1.7, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.85
Holladay 1:SF = 2.06
SRK/T:A = 119.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
PODeye
Monofocal Hydrophobic G-free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
2 mm
hydrophobic
Refractive Index:
1.52		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.4
Haigis:a₀ = 1.7, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.85
Holladay 1:SF = 2.06
SRK/T:A = 119.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
POD F
FineVision Trifocal Hydrophilic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✔ yes

Available Powers

Sphere:6 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.95
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.83
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
POD F GF
FineVision HP Trifocal Hydrophobic G-free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.52		Abbe Number:
42		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:10 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 119.4
Haigis:a₀ = 1.7, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.85
Holladay 1:SF = 2.06
SRK/T:A = 119.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
POD F Toric
FineVision Trifocal Hydrophilic Toric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✔ yes

Available Powers

Sphere:6 to 35 D (increment 0.5 D)
Cylinder:1 to 1.5 D (increment 0.5 D)
2.25 to 6 D (increment 0.75 D)
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.95
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.83
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

PhysIOL
Slimflex
Monofocal Hydrophilic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✔ yes
Optic Ø:
6 mm		Haptic Ø:
10.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
4-loop		Optic Design:
sphere
Sph. Aberration:
none		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.52
Holladay 1:SF = 1.74
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Aurium
Photochromatic

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
photochromic		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.56		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6.1 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.1 µm		Toric:
✘ no

Available Powers

Sphere:0 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.57, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.78
Holladay 1:SF = 2.01
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl Biflex HL
Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
Cylinder:-10 to 9 D (increment 0.5 D)
31 to 45 D (increment 1 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.325, a₁ = 0.255, a₂ = 0.141
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl BiFlex HLY
Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
-10 to 9 D (increment 0.5 D)
31 to 45 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 117.76
Haigis:a₀ = 0.325, a₁ = 0.255, a₂ = 0.141
Hoffer-Q:pACD = 5.01
Holladay 1:SF = 1.25
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl BiFlex MTY Yellow
Multifocal Toric Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sphere:10 to 30 D (increment 0.5 D)
30 to 35 D (increment 1 D)
Cylinder:1 to 4.5 D (increment 0.5 D)
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl BiFlex MY Yellow
Multifocal Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:

Available Powers

Sphere:0 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl BiFlex T Clear
Toric Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sphere:31 to 35 D (increment 1 D)
-10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl BiFlex TY Yellow
Toric Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✔ yes

Available Powers

Sphere:31 to 35 D (increment 1 D)
-10 to 30 D (increment 0.5 D)
Cylinder:1 to 10 D (increment 0.75 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.9
Haigis:a₀ = 0.19, a₁ = 0.192, a₂ = 0.173
Hoffer-Q:pACD = 5.431
Holladay 1:SF = 1.682
SRK/T:A = 118.83
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl S+
Clear lens spheric

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-5 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.98, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.16
Holladay 1:SF = 1.4
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl SHD+
Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.98, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.16
Holladay 1:SF = 1.4
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Domicryl SHD+ Y
Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.4 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:0 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 35 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.98, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.16
Holladay 1:SF = 1.4
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
eyemax mono
AMD IOL

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophobic
Refractive Index:
1.525		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:11 to 25 D (increment 2 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.6
Haigis:a₀ = 1.5, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.65
Holladay 1:SF = 1.88
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Aktis SP clear
Clear lens Glistening free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:1 to 9 D (increment 1 D)
10 to 27 D (increment 0.5 D)
28 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.61, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.81
Holladay 1:SF = 2.03
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Aktis SP yellow
Natural yellow Glistening free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:1 to 9 D (increment 1 D)
10 to 27 D (increment 0.5 D)
28 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.61, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.81
Holladay 1:SF = 2.03
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Nex Acri
Clear lens Glistening free

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:1 to 9 D (increment 1 D)
10 to 27 D (increment 0.5 D)
28 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = 1.55, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.74
Holladay 1:SF = 1.95
SRK/T:A = 119.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Nex Acri AA Aktis
Natural Yellow Glistening free

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.6 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.23 µm		Toric:
✘ no

Available Powers

Sphere:1 to 9 D (increment 1 D)
10 to 27 D (increment 0.5 D)
28 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.34, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.73
SRK/T:A = 118.9
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Nexload System NZ1
Preloaded Clear lens Glistening free

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
J loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:10 to 27 D (increment 0.5 D)
28 D
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 119.2
Haigis:a₀ = 1.73, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.87
Holladay 1:SF = 2.11
SRK/T:A = 119.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Nexload System SZ1
Preloaded Natural yellow Glistening free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:11 to 27 D (increment 0.5 D)
27 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.61, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.81
Holladay 1:SF = 2.03
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Nidek Nexload System SZ1C
Preloaded Clear lens Glistening free

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
0 µm		Toric:
✘ no

Available Powers

Sphere:11 to 27 D (increment 0.5 D)
27 to 30 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.61, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.81
Holladay 1:SF = 2.03
SRK/T:A = 119.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Physiol Ankoris
Monofocal Toric Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✔ yes

Available Powers

Sphere:0 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.95
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.83
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Physiol FineVision Micro F
Multifocal Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6.15 mm		Haptic Ø:
10.75 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
4-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✘ no

Available Powers

Sphere:10 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.8
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.35
Holladay 1:SF = 1.6
SRK/T:A = 118.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Physiol FineVision Pod F
Multifocal Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✔ yes

Available Powers

Sphere:6 to 35 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.95
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.83
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Physiol FineVision Pod FT
Multifocal toric Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Acryl
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2 mm		Injector Size:
2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
58		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11.4 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
Double C-loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.11 µm		Toric:
✔ yes

Available Powers

Sphere:6 to 35 D (increment 0.5 D)
Cylinder:1 to 1.5 D (increment 0.5 D)
2.25 to 6 D (increment 0.75 D)
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118.95
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.59
Holladay 1:SF = 1.83
SRK/T:A = 118.95
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS61
Clear lens

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PVDF
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.12 µm		Toric:
✘ no

Available Powers

Sphere:4 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = -2.993, a₁ = 0.189, a₂ = 0.294
Hoffer-Q:pACD = 5
Holladay 1:SF = 1.24
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS62
Clear lens

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PVDF
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.12 µm		Toric:
✘ no

Available Powers

Sphere:-5 to 5 D (increment 1 D)
5.5 to 34 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = -1.527, a₁ = 0.152, a₂ = 0.237
Hoffer-Q:pACD = 5
Holladay 1:SF = 1.24
SRK/T:A = 118.2
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS64
Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Plattenhaptik		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.12 µm		Toric:
✘ no

Available Powers

Sphere:4 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -1.336, a₁ = 0.272, a₂ = 0.22
Hoffer-Q:pACD = 5.26
Holladay 1:SF = 1.46
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS66
Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.15 µm		Toric:
✘ no

Available Powers

Sphere:-10 to 30 D (increment 0.5 D)
31 to 32 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 0.939, a₁ = 0.25, a₂ = 0.133
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.6
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS66-Y
Natural yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
2.2 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.15 µm		Toric:
✘ no

Available Powers

Sphere:-4 to 9 D (increment 1 D)
10 to 30 D (increment 0.5 D)
31 to 32 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.2
Haigis:a₀ = 0.939, a₁ = 0.25, a₂ = 0.133
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.6
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS68
Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Plattenhaptik		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.12 µm		Toric:
✘ no

Available Powers

Sphere:13 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.54
Holladay 1:SF = 1.74
SRK/T:A = 118.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens AS68Y
Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
1.8 mm
hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Plattenhaptik		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.12 µm		Toric:
✘ no

Available Powers

Sphere:13 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = 1.36, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.54
Holladay 1:SF = 1.74
SRK/T:A = 118.8
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens H50P
Preloaded Clear lens

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens H60P
Preloaded Clear lens

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✔ yes		Foldable:
Incision Width:
2.5 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.093, a₁ = -0.023, a₂ = 0.208
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.54
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Polylens Y50P
Preloaded Natural Yellow

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✔ yes		Foldable:
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.52		Abbe Number:
Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.18 µm		Toric:
✘ no

Available Powers

Sphere:6 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.4
Haigis:a₀ = -0.542, a₁ = 0.161, a₂ = 0.204
Hoffer-Q:pACD = 5.3
Holladay 1:SF = 1.52
SRK/T:A = 118.5
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Polytech Domilens
Precisal 300A
Natural Yellow

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sphere:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.26, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.61
SRK/T:A = 118.7
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = 1.2471 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.3584
Holladay 1:SF = 1.6052
SRK/T:A = 118.626

Calculated from 49 clinical results.

IOL Con

Polytech Domilens
Precisal 300AC
Clear lens

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
PMMA
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.8 mm		Injector Size:

hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
Haptic Design:
Modified C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.06 µm		Toric:
✘ no

Available Powers

Sph. Equivalent:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.3
Haigis:a₀ = 1.26, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.39
Holladay 1:SF = 1.61
SRK/T:A = 118.7
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = 1.2471 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.3584
Holladay 1:SF = 1.6052
SRK/T:A = 118.626

Calculated from 49 clinical results.

IOL Con

Polytech Domilens
Precisal P302A
Preloaded Natural Yellow

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
yellow		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modi ed C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.19 µm		Toric:
✔ yes

Available Powers

Sph. Equivalent:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.70119, a₁ = 0.11934, a₂ = 0.22226
Hoffer-Q:pACD = 5.49901
Holladay 1:SF = 1.74071
SRK/T:A = 118.899

Calculated from 224 clinical results.

IOL Con

Polytech Domilens
Precisal P302AC
Preloaded Clear lens

Specifications

Single Piece:
✘ no		Optic Material:
acrylic		Haptic Material:
acrylic
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:
2.2 mm
hydrophobic
Refractive Index:
1.5		Abbe Number:
50		Achromatic:
✘ no
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
Optic Concept:
Haptic Design:
Modi ed C-Loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.19 µm		Toric:
✘ no

Available Powers

Sph. Equivalent:0 to 10 D (increment 1 D)
10 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118.7
Haigis:a₀ = 1.32, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.51
Holladay 1:SF = 1.75
SRK/T:A = 118.9
Barrett:-
Olsen:-

Adopted from ULIB.

Optimized Constants

Haigis:a₀ = -0.70119, a₁ = 0.11934, a₂ = 0.22226
Hoffer-Q:pACD = 5.49901
Holladay 1:SF = 1.74071
SRK/T:A = 118.899

Calculated from 224 clinical results.

IOL Con

Rayner
RayOne Aspheric
RAO600C

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified-c-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 7 D (increment 1 D)
8 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.17, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:a₀ = 1.3633 (with fixed a₁ = 0.4, a₂ = 0.1)
Hoffer-Q:pACD = 5.471
Holladay 1:SF = 1.67
SRK/T:A = 118.755

Calculated from 87 clinical results.

IOL Con

Rayner
RayOne Hydrophobic
RAO800C

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophobic
Refractive Index:
1.51		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified-c-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 7 D (increment 1 D)
8 to 30 D (increment 0.5 D)
31 to 32 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.17, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
RayOne Spheric
RAO100C

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified-c-loop		Optic Design:
sphere
Sph. Aberration:
SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 7 D (increment 1 D)
8 to 30 D (increment 0.5 D)
31 to 34 D (increment 1 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.17, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
RayOne Toric
RAO610T

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
modified-c-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:-9.5 to 34.5 D (increment 0.5 D)
Cylinder:1 to 11 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.17, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
RayOne Trifocal
RAO603F

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
modified-c-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:0 to 30 D (increment 0.5 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.044, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
RayOne Trifocal Toric
RAO613Z

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✔ yes		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
Achromatic:
Optic Ø:
6 mm		Haptic Ø:
12.5 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
modified-c-loop		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:6 to 30 D (increment 0.5 D)
Cylinder:0.75 to 4.5 D (increment 0.75 D)
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.044, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
Sulcoflex Aspheric
653L

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
56		Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
14 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
undulating and rounded C-loop haptics		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-10 to 10 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
Sulcoflex Toric
653T

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
56		Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
14 mm		Intended Location:
sulcus ciliaris
Optic Concept:
monofocal		Haptic Design:
undulating and rounded C-loop haptics		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✔ yes

Available Powers

Sph. Equivalent:-7 to 7 D (increment 0.5 D)
Cylinder:1 to 6 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

Rayner
Sulcoflex Trifocal
703F

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
2.2 mm		Injector Size:

hydrophilic
Refractive Index:
1.46		Abbe Number:
56		Achromatic:
Optic Ø:
6.5 mm		Haptic Ø:
14 mm		Intended Location:
sulcus ciliaris
Optic Concept:
multifocal		Haptic Design:
undulating and rounded C-loop haptics		Optic Design:
asphere
Sph. Aberration:
neutral		SA Correction:
Toric:
✘ no

Available Powers

Sphere:-3 to 3 D (increment 0.5 D)
-1 to 1 D (increment 0.25 D)
Cylinder:-
Near Addition:3.5 D
Intermediate Addition:1.75 D

Manufacturer Provided Constants

Nominal:-
Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva BB T MFM 611
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.462		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
plate		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.165 µm		Toric:
✔ yes

Available Powers

Sphere:0 to 32 D (increment 0.5 D)
Cylinder:1 to 10 D (increment 0.5 D)
Near Addition:3.75 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.67, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.96
Holladay 1:SF = 1.27
SRK/T:A = 118.3
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva BB T UDM 611
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.462		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
plate		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.165 µm		Toric:
✔ yes

Available Powers

Sphere:0 to 32 D (increment 0.5 D)
Cylinder:1 to 10 D (increment 0.5 D)
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.1, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.28
Holladay 1:SF = 1.56
SRK/T:A = 118.6
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva BB UD 613
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.462		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.165 µm		Toric:

Available Powers

Sphere:0 to 32 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.95, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.19
Holladay 1:SF = 1.43
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva BB UDM 611
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
1.8 mm		Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.462		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
11 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.165 µm		Toric:

Available Powers

Sphere:0 to 32 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 1.15, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.32
Holladay 1:SF = 1.58
SRK/T:A = 118.7
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva HAF
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
clear		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.462		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13.75 mm		Intended Location:
capsular bag
Optic Concept:
monofocal		Haptic Design:
balance		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.165 µm		Toric:

Available Powers

Sphere:0 to 32 D (increment 0.5 D)
Cylinder:-
Near Addition:-
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.89, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 5.11
Holladay 1:SF = 1.33
SRK/T:A = 118.4
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva Reviol BB MF 613
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
acrylic		Haptic Material:
Filter:
yellow		Preloaded:
✘ no		Foldable:
✔ yes
Incision Width:
Injector Size:
Hydrophilic/ ‑phobic:
Refractive Index:
1.462		Abbe Number:
58		Achromatic:
Optic Ø:
6 mm		Haptic Ø:
13 mm		Intended Location:
capsular bag
Optic Concept:
multifocal		Haptic Design:
C loop		Optic Design:
asphere
Sph. Aberration:
correcting		SA Correction:
-0.165 µm		Toric:

Available Powers

Sphere:0 to 32 D (increment 0.5 D)
Cylinder:-
Near Addition:3.75 D
Intermediate Addition:-

Manufacturer Provided Constants

Nominal:A = 118
Haigis:a₀ = 0.65, a₁ = 0.4, a₂ = 0.1
Hoffer-Q:pACD = 4.93
Holladay 1:SF = 1.2
SRK/T:A = 118.1
Barrett:-
Olsen:-

Optimized Constants

Haigis:-
Hoffer-Q:-
Holladay 1:-
SRK/T:-

Calculated from 0 clinical results.

IOL Con

VSY Biotechnology
Acriva Reviol BB MFM 611
VSY Biotechnology

Specifications

Single Piece:
✔ yes		Optic Material:
a
